47
Configuration > Advanced > Video (Continued)
Using the DCS-3220G with an Internet
browser (continued)
Video quality control-
Flip - Vertically rotate the video.
To fix the bandwidth utilization regardless of the video
quality, choose Fix bit rate and select the desired
bandwidth. The video quality may be reduced in
order to send maximum frames with limited
bandwidth, especially when images change
drastically. For higher video detail regardless of the
bandwidth selection, select Fix quality and select
a video quality level. This setting will utilize more
bandwidth to send the maximum frames when
images change drastically.
Mirror - Horizontally rotate the video. Check both flip and
mirror if the DCS-3220G is to be installed upside
down.
Click Apply to make
changes effective
Improve efficiency in
the multi-user
environment -
If the camera works in a multi-user environment,
the user can select this to conserve bandwidth by
reducing video capture rate.
