D-Link DCS-3220G [91/143] Using ip surveillance software continued

Using IP surveillance Software (continued)

Double click on a

display window to

switch to a single

channel layout.

When you choose the one-channel layout or four-channel layout, the “Page up”

and “Page down” buttons will be shown in the left-bottom corner of the video

area. You can use these two buttons to switch the pages, as shown in the

figure below.

Use to switch between

cameras.

Monitor Program (continued)
