D-Link DCS-3220G [13/143] Installation wizard continued
![D-Link DCS-3220G [13/143] Installation wizard continued](/views2/1043917/page13/bgd.png)
13
After you click on the Link to
Selected Devices button,
Installation Wizard will
automatically open your
Internet browser to the IP
Address of the DCS-3220G,
in this example it is: http://
192.168.0.12. Your DCS-
3220G may have a different
IP Address.
You have now completed the Setup Wizard and are ready to use your
camera! You can also continue to the section titled “Installing IP
surveillance Software” (page 21) to install the IP surveillance software
before you begin to use the DCS-3220G.
For more information regarding the functions of this screen, see the following
section titled “Installation Wizard Screen.”
The Installation Wizard will now show a MAC address for the DCS-3220G
and an IP address. This IP address may not be correct at this step in the
installation until you see “Yes” under the assigned column. The camera is now
automatically configured with an IP address consistent to the device it is
connected to.
Click on the Link to Selected
Devices button.
Select the MAC address.
Installation Wizard (continued)
