Enabling UPnP for Windows XP/Me
UPnP is short for Universal Plug and Play, which is a networking architecture
that provides compatibility among networking equipment, software, and
peripherals. The DCS-3220G is a UPnP enabled Internet camera. If your
operating system is UPnP enabled, the device will be easier to configure. If you
do not want to use the UPnP functionality, it can be disabled by unchecking the
Enabled DDNS checkbox in the DDNS/UPnP settings page under “Advanced”
in the configuration menu. Use the following steps to enable UPnP (Universal
Plug and Play) settings only if you are running Windows XP/Me. If you are running
Windows 98/2000, UPnP is not available.
Click Control Panel
Go to Start >Settings.
Click Add or Remove
Programs
