D-Link DCS-3220G [31/143] Using configuring the dcs 3220g with a nat router continued

Important: Some ISPs block access to port 80 and other commonly used

Internet ports to conserve bandwidth. Check with your ISP so that you can

open the appropriate ports accordingly. If your ISP does not pass traffic on port

80, you will need to change the port the camera uses from 80 to something

else, such as 800. Not all routers are the same, so refer to your user manual

for specific instructions on how to open ports.

Using & Configuring the DCS-3220G with a

NAT Router (continued)

Enter the ports in the Virtual

Server section of your router

that correspond ot the ports

you have configured on the

DCS-3220G.

192.168.0.102

Follow these steps to configure your router’s Virtual Server settings:

Repeat the above steps adding ports 5002 and 5003 to both the Public and

Private Port sections. A check mark appearing before the entry name will

indicate that the ports are enabled.

• Click Enabled.

• Enter a different name for each entry.

• Enter your camera’s local IP Address (e.g., 192.168.0.102 in

the example in step



 on page 28) in the Private IP field.

• Select Both under Protocol Type (TCP and UDP)

• If you are using the default camera port settings, enter 80 into

the Public and Private Port section, click Apply.

• Scheduling should be set to Always so that the camera images

can be accessed at any time.

Please make sure to check

the box on this line to enable

settings
