53
Guest account: This option allows a user to connect to a camera with
view-only privileges. User name is demo. No password
is required. This is useful for demonstrations and keeps
guests separate from users with accounts.
Configuration > Tools > System
Click on the System button to access the System settings from the Tools
menu.
Camera name -
Using the DCS-3220G with an Internet
browser (continued)
Check this option to shut off the LED next to the lens.
This will prevent anyone from observing the operation of
the Internet Camera.
The text will display as the title of the window within the
Windows operating system. This name will also display
on the log-in screen (once a password has been set).
Illegal characters (*,&,/) are not allowed and may render
the recording feature in IP surveillance (page 65) useless
for that camera.
Turn off the LED
indicator -
Configuration > Tools > Admin (continued)
Camera name
Click System
