D-Link DCS-3220G [50/143] Using the dcs 3220g with an internet browser continued
![D-Link DCS-3220G [50/143] Using the dcs 3220g with an internet browser continued](/views2/1043917/page50/bg32.png)
50
Configuration > Advanced > Motion Detection
Click the Motion Detection button from the Configuration screen to access
settings that affect how the DCS-3220G Internet Camera can serve as a security
device by recording only when motion is detected.
Using the DCS-3220G with an Internet
browser (continued)
From this screen you can fine tune the video image.
Image Brightness, Contrast, Saturation and Hue are all adjusted in the same
manner. For each video compensation you can set from among eleven levels
ranged from -5 to +5. The default setting is zero for each adjustment.
You may press
to fine-tune the image and see what affect the setting
will have on the image. When the image is acceptable, press
to store the
image settings, or to recall the original settings. If settings are changed
without saving, they will be used until the next system start-up.
Click Motion Detection
