D-Link DCS-3220G [20/143] Enabling upnp for windows xp me continued

Click My Network Places

To view your DCS-3220G

Internet Camera in an Internet

browser, go to your Desktop

and click My Network

Places.

Click DCS-3220G-12

The last digit(s) (12), represent

the fourth octet of your Internet

Camera’s IP address (in this

example, 198.168.0.12).

After you click on the DCS-

3220G-12 icon, your Internet

browser will automatically be

opened to the IP Address of the

DCS-3220G, in this example it

is: http://192.168.0.12. Your

DCS-3220G may have a differ-

ent IP Address.

(Note: Screen shots are taken in Windows XP, similar screens will appear in Windows Me.)

Enabling UPnP for Windows XP/Me

(continued)
