D-Link DCS-3220G [49/143] Using the dcs 3220g with an internet browser continued

Recommendations for setting video for the best

performance (continued):

Recording Settings to compromise between real-time and clear

images

Click the Image Setting button from the Configuration screen to access additional

settings that affect how the video image appears.

Using the DCS-3220G with an Internet

browser (continued)

Configuration > Advanced > Image Setting

If you have a broadband network, set Fix quality to Good image quality, or

higher, instead of setting the Bit rate. Otherwise, fix the bit rate according to

your actual network speed and set the frame rate to 30. If the image quality is

low, select a lower frame rate above 15.

Click Image Setting
