D-Link DCS-3220G [18/143] Enabling upnp for windows xp me continued

Click Add/Remove

Windows Components

The following screen will

appear:

Select Networking Services

(Communications in Windows

Me)

Click Details

Select Universal

Plug and Play

Click Ok

Enabling UPnP for Windows XP/Me

(continued)
