16
Installation Wizard Screen (continued)
Reset to Default -
About -
Exit -
Click the Exit tab to exit the Installation Wizard screen.
Click About to display the current
version and date.
Click the Reset to Default tab to reset the camera’s settings to factory defaults.
Locate the Firmware to Upgrade -
Indicate the location of the firmware to be uploaded to the camera.
Selected Package -
This displays the file name of the firmware selected for upload.
The upgrade window allows users
to upload a saved firmware file. If
the firmware is older than that
currently on the camera, a screen
will appear indicating so and
prompting the user to confirm the
upload.
Package Information -
This displays information about the
firmware and plugin currently
installed on the camera.
Upgrade -
