43
Click Apply to make
changes effective
Using the DCS-3220G with an Internet
browser (continued)
Configuration > Advanced > Mail & FTP (Continued)
2nd FTP user name - Granted user name on the backup FTP server.
2nd FTP password - Granted password on the backup FTP server.
2nd FTP server - The domain name or IP address of the external
FTP server. Note that this 2nd FTP server will
only be used if the 1st FTP server is unavailable.
If image upload to the 1st FTP server is
successful, no attempts will be made to connect
to the 2nd FTP server.
2nd FTP remote folder - Granted folder on the backup FTP server.
Mode - Passive mode setting for the backup FTP server.
Secondary FTP passive
Invalid settings may cause the DCS-3220G to not respond. Change the
configuration settings only if necessary. Consult with your network
administrator or your Internet Service Provider (ISP) if you do not have the
necessary information. If you cannot connect to the camera, refer to page
128 for camera reset and restore factory settings procedures.
If the DCS-3220G is located inside a network that
is protected by a firewall, a data connection for
FTP may be prohibited. Passive mode FTP can
bypass this rule and allow the uploading of
snapshots. If the passive mode is selected, the
DCS-3220G can automatically attempt to upload
in active mode if the external FTP server does
not support passive mode.
Primary FTP Passive
Mode-
