Fluke 190 [100/159] Printing a screen
![Fluke 190 [100/159] Printing a screen](/views2/1005075/page100/bg64.png)
Fluke 19xC-2x5C
Users Manual
90
Whenever possible, choose the option Postscript when
printing screens. This option gives the best printing results.
Consult the manual that came with your printer to find out
whether it has Postscript printing possibilities.
To connect the SII (Seiko Instruments Inc.) DPU-414
thermal printer you must use the printer adapter cable
PAC91. (See
Figure 50)
Printing a Screen
To print the currently displayed screen, do the following:
1
Clear the menu if you do not want
to print it.
2
Display the SAVE/PRINT key labels.
3
Start printing.
A message appears at the bottom of the screen indicating
that the test tool is busy printing.
Screens will be printed in black and white.
