Specifications

Electromagnetic Immunity

129

Electromagnetic Immunity

The Fluke 19xC-2x5C series, including standard accessories, conforms with the EEC directive 2004/108/EC for EMC

immunity, as defined by EN-61326-1:2006, with the addition of the following tables.

Scope Mode (10 ms/div): Trace disturbance with VPS210 voltage probe shorted

Table 12

No visible disturbance E = 3V/m

Frequency range 10 kHz to 20 MHz 2 mV/div to 100 V/div

Frequency range 20 MHz to 100 MHz 200 mV/div to 100 V/div

Frequency range 100 MHz to 1 GHz

Frequency range 1.4 GHz to 2.0 GHz

500 mV/div to 100 V/div

2 mV/div to 100 V/div

(*) With the 20 MHz Bandwidth Filter switched on: no visible disturbance.

With the 20 MHz Bandwidth Filter switched off: disturbance is max 2 div.

Table 13

No visible disturbance E = 1V/m

Frequency range 2.0 GHz to 2.7 GHz 2 mV/div to 100 V/div

Table 14

Disturbance less than 10% of full scale E = 3V/m

Frequency range 20 MHz to 100 MHz 10 mV/div to 100 mV/div

Test Tool ranges not specified in tables 12, 13 and 14 may have a disturbance of more than 10% of full scale.
