Fluke 190 [138/159] Environmental
![Fluke 190 [138/159] Environmental](/views2/1005075/page138/bg8a.png)
Fluke 19xC-2x5C
Users Manual
128
Environmental
Temperature
Operating ............................. 0 to 50 °C (32 to 122 °F)
Storage ..........................-20 to +60 °C (-4 to +140 °F)
Altitude
Operating ....................................... 3 km (10 000 feet)
Storage ........................................ 12 km (40 000 feet)
Humidity
Operating at 10 to 30 °C (50 to 86 °F) ............... 95 %
0.01
1
2
5
10
20
50
100
200
500
1000
0.02 0.05 0.1 0.2 0.5 1 2 5 10 20 50 100 20
0
FREQUENCY (MHz)
MAX
.
INPUT
VOLTAGE (Vrms)
CAT III
CAT II
Figure 64. Max. Voltage From Probe Tip to earth
ground and From Probe Tip to Probe Reference
