![Fluke 190 [117/159] Replacement parts](/views2/1005075/page117/bg75.png)
Maintaining the Test Tool
Parts and Accessories
9
107
Replacement Parts
Item Ordering Code
Battery Charger, available models:
Universal Europe 230 V, 50 and 60 Hz
North America 120 V, 50 and 60 Hz
United Kingdom 240 V, 50 and 60 Hz
Japan 100 V, 50 and 60 Hz
Australia 240 V, 50 and 60 Hz
Universal 115 V/230 V, 50 and 60 Hz
*
* UL listing applies to BC190/808 with UL listed line plug adapter for
North America.
The 230 V rating of the BC190/808 is not for use in North America.
For other countries, a line plug adapter complying with the
applicable National Requirements must be used.
BC190/801
BC190/813
BC190/804
BC190/806
BC190/807
BC190/808
Voltage Probe Set (Red), designed for use with the Fluke ScopeMeter
19xC-2x5C series test tool.
The set includes the following items (not available separately):
• 10:1 Voltage Probe (red)
• 4-mm Test Probe for Probe Tip (red)
• Hook Clip for Probe Tip (red)
• Ground Lead with Hook Clip (red)
• Ground Lead with Mini Alligator Clip (black)
• Ground Spring for Probe Tip (black)
• Insulation Sleeve (red)
VPS210-R
