![Fluke 190 [133/159] Zoom replay and cursors](/views2/1005075/page133/bg85.png)
Specifications
Zoom, Replay and Cursors
10
123
Zoom, Replay and Cursors
Zoom
Horizontal Magnification
Scope Record .............................................. up to 120x
TrendPlot ........................................................up to 96x
Scope................................................................up to 8x
Replay
Displays a maximum of 100 captured dual input Scope
screens.
Replay modes........... Step by Step, Replay as Animation
Cursor Measurements
Cursor Modes ..................................single vertical cursor
dual vertical cursors
dual horizontal cursors (Scope mode)
Markers....................... automatic markers at cross points
Measurements ....................................... value at cursor 1
value at cursor 2
difference between values at cursor 1 and 2
time between cursors,
RMS between cursors
Time of Day (Recorder modes)
Time from Start (Recorder modes)
Rise Time
Fieldbus – Bushealth
Type Subtype Protocol
AS-i NEN-EN50295
CAN ISO-11898-2
Modbus RS-232
RS-485
RS-232/EIA-232
RS-485/EIA-485
Foundation
Fieldbus
H1 61158 type 1, 31.25 kBit/s
Profibus DP
PA
EIA-485
61158 type 1
Ethernet Coax
TP
TP
10Base2
10BaseT
100BaseT
RS-232 EIA-232
RS-485 EIA-485
