Fluke 19xC-2x5C
Users Manual
36
Changing the Recorder Options
At the right bottom of the display you can choose to
display the time elapsed from start and the actual time of
the day.
To change the time reference, proceed from step 6 as
follows:
7
Open the Recorder Options
menu.
8
Select Time of Day or From
Start
Now the recorded time or the current time appear at the
bottom of the screen.
Turning Off the TrendPlot Display
9
Exit the recorder function.
