Using The Scope
Making Scope Connections
1
11
Making Scope Connections
To make dual input scope measurements, connect the red
voltage probe to input A, and the gray voltage probe to
input B. Connect the short ground leads of each voltage
probe to its own reference potential. (See
Figure 6.)
Note
To maximally benefit from having independently
isolated floating inputs and to avoid problems
caused by improper use, read Chapter 8: “Tips”.
Figure 6. Scope Connections
