Chapter 3
Using The Recorder Functions
About this Chapter
This chapter provides a step-by-step introduction to the
recorder functions of the test tool. The introduction gives
examples to show how to use the menus and perform
basic operations.
Opening the Recorder Main Menu
First choose a measurement in scope or meter mode. Now
you can choose the recorder functions from the recorder
main menu. To open the main menu, do the following:
1
RECORDER
ANALYZE
Open the RECORDER main menu.
(See Figure 17.)
Figure 17. Recorder Main Menu
