Fluke 190 [58/159] Using cursors on a a b a b or a b waveform

Fluke 19xC-2x5C

Users Manual

Using Cursors on a A+B, A-B or A*B Waveform

Cursor measurements on a A*B waveform give a reading

in Watts if input A measures (milli)Volts and input B

measures (milli)Amperes.

For other cursor measurements on a A+B, A-B or A*B

waveform no reading will be available if the input A and

input B measurement unit are different.

Using Cursors on Spectrum Measurements

To do a cursor measurent on a spectrum, do the following:

From Spectrum measurement

display the cursor key label.

Move the cursor and observe the

readings at the top of the screen.
