Fluke 190 [41/159] Freezing the readings

Using The Multimeter

Freezing the Readings

You can freeze the displayed readings at any time.

Freeze the screen. HOLD appears

at the top right of the reading

area.

Resume your measurement.

You can use this function to hold accurate readings for

later examination.

Note

For saving screens into memory, see Chapter 7.

Selecting Auto/Manual Ranges

To activate manual ranging, do the following during any

Meter measurement:

Activate manual ranging.

2 Increase or decrease the range.

Observe how the bargraph sensitivity changes.

Use manual ranging to set a fixed bargraph sensitivity and

decimal point.

Choose auto ranging again.

When in auto ranging, the bargraph sensitivity and decimal

point are automatically adjusted while checking different

signals.
