Tips
Changing the Display Color
8
97
Changing the Display Color
To set the display to color or Black and White, do the
following:
1
Display the USER key labels.
2
Open the User Options menu.
3
Open Display Options menu.
4
Choose display mode Color or
Black and White, and accept it.
Changing Date and Time
The test tool has a date and time clock. For example, to
change the date to 19 April, 2002, do the following:
1
Display the USER key labels.
2
Open the User Options menu.
3
Open Date Adjust menu.
4
Choose 2002, jump to Month.
5
Choose 04, jump to Day.
