Fluke 19xC-2x5C
Users Manual
108
Item Ordering Code
Voltage Probe Set (Gray), designed for use with the Fluke ScopeMeter
19xC-2x5C series test tool.
The set includes the following items (not available separately):
• 10:1 Voltage Probe (gray)
• 4-mm Test Probe for Probe Tip (gray)
• Hook Clip for Probe Tip (gray)
• Ground Lead with Hook Clip (gray)
• Ground Lead with Mini Alligator Clip (black)
• Ground Spring for Probe Tip (black)
• Insulation Sleeve (gray)
VPS210-G
Test Lead Set (red and black)
TL75
Accessory Set (Red)
The set includes the following items (not available separately):
• Industrial Alligator for Probe Tip (red)
• 2-mm Test Probe for Probe Tip (red)
• Industrial Alligator for Banana Jack (red)
• 2-mm Test Probe for Banana Jack (red)
• Ground Lead with 4-mm Banana Jack (black)
AS200-R
