Инструкция по эксплуатации Страница: 74

Fluke 190 Инструкция по эксплуатации онлайн [74/159] 4548

Fluke 19xC-2x5C

Users Manual

To set the pulse width to 150 ms, continue as follows:

Enable the arrow keys to adjust

the pulse width.

Select 150 ms.

Figure 34. Triggering on Missing Pulses
