High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 115
command. When torque control mode is used, the motor speed may increase to dangerous speed because
the torque command does not match the load torque. Please remember to set the speed limiting value.
Digital setting of speed limiting value: Refer to the description of forward maximum speed limiting value
Pd.06 and reverse maximum speed limiting value Pd.07.
Analog setting of speed limiting value: Refer to the description of analog channel function selection.
When analog channel input is used to realize the speed limiting, function codes Pd.06 and Pd.07 are
invalid.
Note:
Input torque reference from analog channel when operating under torque control mode. Refer to
instructions of P6.21.
The jogging command is invalid under torque control.
Under vector control 2, it can be switched between speed control mode and torque control mode
through terminal. If Pd.00 is set as 0 and the terminal function is invalid, it is under speed control. If
the terminal function is valid, it switches to torque control. If Pd.00 is set as 1 and the terminal
function is invalid, it is under torque control. If the terminal function is valid, it switches to speed
control. Refer to the description of the terminal function of multi-functional terminals P5.00 to P5.06:
“64: speed control/torque control switching”.
Adjust proportional gain and integral time for the speed regulator.
Proportional gain P:
In the case of vector control 2 without encoder speed feedback, the leave-factory value of this parameter
is 2.00. In the case of vector control 2 with encoder speed feedback, the leave-factory value is 3.00.
Adjust according to rotating inertia of machines connecting with motor. For machines with large rotating
inertias, please increase P gain; for machines with small rotating inertias, please decrease P gain.
When P gain is greater than inertia, although the control response can be accelerated, the motor may
shock or overshoot. Reversely, if P gain is smaller than inertia, the control response will get slower and
the time taken to adjust the speed to the stable value will longer.
Integral time I:
The integral is invalid when setting the integral time I to 0 (controlled by P alone). To ensure the
difference between the speed instructions and real speed is 0 under steady-state conditions, set the
integral time I to non-0 values. When I value is smaller, the system responses quickly. But if the value is
very small, shock will occur. If I value is greater, the system responds slowly.
Adjust PI settings when operating quickly or slowly:
Pd.01
Speed loop proportional gain 1 (ASR_P1)
0.000~6.000(2.00or3.00)
Pd.02 Speed loop integral time 1 (ASR_I1)
0.000~6.000 s(0.200)
Pd.03 Speed loop proportional gain 2 (ASR_P2)
0.000~6.000(2.00or3.00)
Pd.04 Speed loop integral time 2 (ASR_I2)
0.000~6.000 s(0.200s)
Pd.05 ASR switching frequency
0.00~300.00 Hz(5.00Hz)
