Translation of the original instructions TECHNICAL SPECIFICATIONS ENGINE ROBIN SUBARU EX27 265cc 8 3HP one cylinder 4 stroke petrol LOMBARDINI 15LD350 349cc 7 5HP one cylinder diesel STARTER recoil and electric starter are both available FUEL TANK 6 1 litres EX27 4 3 litres 15LD350 HOURLY CONSUMPTION 2 4 litres EX27 1 5 litres 15LD350 GEARBOX oil bath gears with 7 gears 4 forward gears and three reverse gears SPEED l 1 km h ll 2 6 lll 4 2 km h IV 11 km h l RM 1 km h ll RM 2 6 km h lll RM 3 6 TRACTION rubber tracks with internal steel links STEERING with clutches in oil bath combines with brakes LOAD BODY 1050x650x200 mm forward tipping system with dump sides DUMPER 230 litres reclining forward LOAD CAPACITY 500 kg SAFETY DEVICES automatic handbrake P T O 965 r p m TRACK BEARING SURFACE 700 mm TRACK WIDTH 650 mm ATTACHMENTS hydraulic lift with P T O at 965 r p m 68 cm all purpose flail 70 cm snow thrower 125 cm front blade reclining body shock absorber operator s board 100 cm orientable sweeper PUTTING THE MACHINE INTO SERVICE 1 Check that the machine has not been damaged in transit 2 Check the engine oil level 3 Check the hydraulic oil level if necessary 4 Check the battery voltage it must not be lower than 12 5 V If necessary charge the battery CAUTION During assembly take care not to get the polarity of the battery reversed Do not start the engine if the battery has not been well connected BATTERY CAUTION Acids inside the battery are highly explosive always keep them away from sparks and flames Regularly check the terminals and keep them lubricated with grease RUNNING IN CAUTION Change the oil after the first 20 hours Check that there are no oil leakages or loose screws 9
