Grillo Dumper 507 [14/57] Maintenance summary table

Содержание

• Dumper 507 1
• Grillo 1
• Danger 5
• General security rules norme di carattere generale sulla sicurezza sicherheitshinweise règles générales de sécurité normas de carácter general sobre la seguridad normas de carácter general acerca da segurança 5
• A tençào 6
• Achtung 6
• Adanger 6
• Attention 6
• Attenzione 6
• Peligro 6
• Warning 6
• Dumper 507 7
• General description and intended use 8
• Tracked carrier 8
• Warnings 8
• Identification and servicing 9
• _562100 9
• Putting the machine into service 10
• Technical specifications 10
• Finishing work 11
• Instructions for use 11
• Maintenance and lubrication 11
• Starting the engine 11
• Starting the machine 11
• Rubber crawler tracks precautions for use 13
• Maintenance summary table 14
• Implements 15
• Descrizione generale ed uso previsto 16
• Dumper 507 16
• Motocarriola cingolata 16
• Grillo 17
• Identificazione e assistenza 17
• U7z 2012 17
• Caratteristiche tecniche 18
• Avviamento del motore 19
• Avviamento della macchina 19
• Istruzioni d uso 19
• Messa in opera della macchina 19
• Filtro aria 20
• Fine lavoro 20
• Manutenzione e lubrificazione 20
• Olio cambio 20
• Olio motore 20
• Rulli cingoli 20
• Evitare bruschi cambi di direzione 21
• Fig 10 tension del cingolo in gomma 21
• Precauzioni nella guida 21
• Precauzioni per l uso del cingolo in gomma 21
• Regole utili per il buon uso 21
• Tensione del cingolo fig 6 21
• Evitare contaminazioni con olio 22
• Leve e frenidi sterzo 22
• Manutenzione di fine stagione 22
• Regolazioni 22
• Sostituzione della ruota dentata 22
• Temperatura d esercizio 22
• Tendicinghia avanzamento 22
• Attrezzi 23
• Tabella riassuntiva manutenzione 23
• Description generale et usage prevu 25
• Dumper 507 25
• Transporteur a chenilles 25
• Gnillo 26
• Identification et assistance 26
• U7z 2012 26
• Caracteristiques techniques 27
• Mise en service de la machine 28
• Mode d emploi 28
• Maintenance et lubrication 29
• Precautions pour l emploi des chenilles en caoutchouc 30
• Outils 32
• Tableau recapitulatif de maintenance 32
• Allgemeine beschreibung und vorgesehener gebrauch 34
• Dumper 507 34
• Raupentransporter 34
• Grnllo 35
• Identifikation der maschine und kundendienst 35
• L564127 35
• U7z 2012 35
• Inbetriebnahme der maschine 36
• Technische daten 36
• Betriebsanleitung 37
• Wartung und schmierung 37
• Abb 10 spannung der gummiraupe 39
• Gummiraupen wichtige hinweise 39
• Zubehöre 41
• Carretilla de orugas 42
• Descripción general y uso previsto 42
• Dumper 507 42
• Identificación y asistencia 43
• U7z ye 2012 43
• Puesta en servicio de la máquina 44
• Instrucciones de uso 45
• Mantenimiento y lubricacion 46
• Fig 10 tensión de la cremallera de goma 47
• Precauciones para el uso de la cremallera de goma 47
• Equipos 49
• Fig 21 55
• Fig 22 55
• Gfrsllo 57

Похожие устройства

• Grillo Dumper 406 Инструкция по эксплуатации
• Grillo Climber 10 AWD 27 Инструкция по эксплуатации
• Grillo Climber 10 AWD 22 Инструкция по эксплуатации
• Grillo Climber 9.27 Инструкция по эксплуатации
• Grillo Climber 9.22 Инструкция по эксплуатации
• Grillo Climber 9.18 Инструкция по эксплуатации
• Grillo Climber 8.22 Инструкция по эксплуатации
• Grillo Climber 7.18 Инструкция по эксплуатации
• Grillo CL 75 Инструкция по эксплуатации
• Grillo CL 62 Инструкция по эксплуатации
• Grillo GH 9 Инструкция по эксплуатации
• Grillo GH 7 Инструкция по эксплуатации
• Grillo Climber 9.21 MP Инструкция по эксплуатации
• Grillo Climber 9.21 Инструкция по эксплуатации
• Grillo Climber 9.16 Инструкция по эксплуатации
• Grillo Climber 910 Инструкция по эксплуатации
• Grillo Climber 780 PLUS Инструкция по эксплуатации
• Grillo Climber 780 Инструкция по эксплуатации
• Grillo Climber 7.22 Инструкция по эксплуатации
• Grillo Climber 7.21 Инструкция по эксплуатации

Translation of the original instructions ADJUSTMENTS The steering levers are adjusted using the two lock nuts fig 12 The steering clutch consists of a perforated disc which is engaged by a lever when the lever is not in the hole there must be 0 3 mm clearance on the rod secured by the lock nut fig 13 How to adjust the steering Lift the machine from the ground Firmly tighten the two nuts fig 12 bold black arrow on the right hand side Start the engine put the gearbox on the first gear and engage the forward lever This way the rubber track does not turn therefore slowly unscrew the nuts fig 12 bold black arrow on the right hand side when the rubber track is in motion unscrew the nuts for one more revolution Adjust the brake there must be a 6 mm play fig 13 CAUTION when the rubber starts to move it can be dangerous Lubricate the shafts and the springs on the gearbox STEERING BRAKES AND LEVERS Please note this adjustment must be carried out by an authorized Grillo service centre Lift the machine from the ground and tighten the two self locking nuts completely please refer to fig 12 black arrows on the right hand side of the picture Now start the engine put the gearbox on the first gear and engage the feed lever the rubber tracks do not turn slowly unscrew the two self locking nuts fig 12 As soon as the tracks start moving unscrew the nuts for one more revolution Caution never touch the tracks whilst carrying out adjustments The brake rods must have a 6 mm clearance fig 14 push on the lever controlling the brake shoes until contact is made then adjust the nut TRACTION BELT STRETCHER Check that the clearance on the stretcher is sufficient to avoid pulling the belt into the stop position During work there must be traction on the stretcher spring Fig 15 END OF SEASON MAINTENANCE Wash the machine carefully and change the engine and gearbox oil If parts have been damaged during the working season now is the time to put things right Never keep the machine close to chemical fertilizers since some parts might rust MAINTENANCE SUMMARY TABLE PROCEDURE Engine oil EVERY 8 HOURS check the level AFTER 20 HOURS Air filter _ Spark plug replace check adjust Check the level replace Check that the engine intake grid is clean ONCEA YEAR OR EVERY 200 HOURS replace Gearbox oil EVERY 100 HOURS change check EVERY 50 HOURS recommended procedure procedure to be carried out if necessary 13
