Translation of the original instructions IMPLEMENTS DUMPER BODY This type of body has been designed for transporting loose material such as sand gravel soil etc It is equipped with closed toeboards with automatic front opening when the tipper is activated The Dumper body has a quick release hitch for replacing it with the normal body in this case remove the two pins and take out the two bolts fig 16 One person can do this on their own by lowering out the support feet and opening the front toeboard fig 17 SHOCK ABSORBED OPERATOR BOARD This can fit on all models It is used when the operator wishes to be transported by the machine the body however must be loaded This is useful for anyone having to travel over long distances It can be folded back when working from the ground fig 18 HYDRAULIC LIFT WITH FRONT PTO This accessory can fitted on all models It is used for activating equipment such as sprayer pumps biological grinding mills log splitters front scrapers rotary cutters or snow throwers but for the last of these the 8 5HP petrol or diesel engine is recommended The front standard GRILLO flanging is a telescopic flange that can be stretched to the front and the shaft rotates at 965 r p m by disconnecting the lifting jack the body tipping mechanism can be connected fig 19 ALL PURPOSE FLAIL It is 68cm wide has a roller fitted with swinging у tines and is able to cut tall grass tough stalks and small shrubs into fine pieces it can also twigs etc after pruning Used with mower blades instead of the у tines it gives excellent results on smooth lawns fig 23 Caution danger The rotating blades of the all purpose flail are highly dangerous Never put hands or feet under the all purpose flail Never clean the attachment when the engine is running SNOW THROWER This implement is very useful for clearing snow from yards driveways etc It consists of a turbine rotary unit enclosed in a special case open at the front which rotates at high speed collecting the snow and throwing it along a pipe The pipe angle can be adjusted to throw the snow in any direction to a distance of 8 10 metres The snow thrower is fixed to the implement flange using two nuts The snow thrower is 70 cm wide and can clear snow up to 40 cm deep If the snow is very wet keep the ejection pipe turned forward to avoid obstructions at the outlet The two side skids must be adjusted so that they just skim level ground asphalted streets or keep the snow thrower high if the ground is uneven fig 24 Maintenance when work is over remove any snow left in the snow thrower so it cannot freeze and block the turbine Do not clean the attachment when the engine is running Attention danger Do not touch the snow thrower while it is working TILTING FRONT BLADE 125 cm This highly resistant device is ideal for removing snow and levelling mounds of soil or gravel May be tilted to the right and left fig 25 PIVOTING BRUSH 100 cm This brush is very useful to clean roads and squares It can also be used to clean up 10 12 cm high fresh snow and it can be steered left or right to make drifts fig 26 14
