ESIE05-07 Functional Control for a Standalone Unit

Part 2 – Functional Description 2–57

Screen 8a1 This additional screen appears when the schedule timer is enabled.

This screen is only visible if the unit is operating as a standalone unit or if the unit is the master in a

DICN setup.

For each group mentioned in the above table up to 4 additional screens will follow.

Screen 8b1 This additional screen appears when the schedule timer is enabled and one or more days are

dedicated to a group.

This screen is only visible if the unit is operating as a standalone unit or if the unit is the master in a

DICN setup.

Possible operation time settings:

Line n° Display Description Possible settings

1 SCHEDULE TIMER screen title

2 MON: THU: SAT: To allocate a certain group to one of

these days

-, G1, G2, G3 or G4

3 TUE: FRI: SUN: To allocate a certain group to one of

these days

-, G1, G2, G3 or G4

4 WED: To allocate a certain group to this

day

-, G1, G2, G3 or G4

Line n° Display Description

1a GROUP 1/2/3/4:01 TO 03 To set action 1 to 3 for group 1.

1b GROUP 1/2/3/4:04 TO 06 To set action 4 to 6 for group 1.

1c GROUP 1/2/3/4:07 TO 09 To set action 7 to 9 for group 1.

1d HOLIDAY To set actions for the holiday period

2 X:00h00 - 00.0

To set one of the nine times and actions

And specify a setpoint or capacity limitation.

( see below for possibilities )

3 X:00h00 - 00.0

4 X:00h00 - 00.0

Lower limit Upper limit Step Default

00h00 23h59 1 min 00h00
