Functional Control for a Standalone Unit ESIE05-07
2–58 Part 2 – Functional Description
3
1
2
4
5
Possible action
setting
Remark:
P In the user settings menu it is possible to assign every day of the week to one of the four groups.
Then 1 to 9 actions can be assigned to each group.
P The holiday timer can be applied to up 12 holiday periods and up to 9 actions can be assigned to
this group.
P The operation mode of the unit will depend on the last command it has received. This can be from
the timer, the terminal or BMS.
P The values of ISP1 (2) E, OSP1 (2) E and ISP1 (2) C can be chosen and can thus be different from
the values stated in the setpoint menu.
Possible content of 1 action Air-cooled
Evaporator
-less
Water
-cooled
Condenser
-less
Nr. Display Description EWAP/
EWAD
EWTP ERAP EWWD EWLD
CO HR CA HP RC
0 - No action O -- O O O
1ON On OO O O O
2 ON COOL On and Cooling -- -- -- O --
3 ON HEAT On and heating -- -- -- O --
4OFF Off O O O O O
5 LIM1 Activate Limitation 1 O O O O O
6 LIM2 Activate Limitation 2 O O O O O
7 LIM3 Activate Limitation 3 O O O O O
8 LIM4 Activate Limitation 4 O O O O O
9 NO LIM Disactivate limitation O O O O O
10 LOWNOIS Activate Low noise O O O -- O
11 NO-LOWN Disactivate Low noise O O O -- O
12 ISP 1 E: Inlet set point 1 Evaporator O O -- O O
13 ISP 2 E: Inlet set point 2 Evaporator O O -- O O
14 OSP 1 E: Outlet set point 1 Evaporator O O -- O O
15 OSP 2 E: Outlet set point 2 Evaporator O O -- O O
16 ISP 1 C: Inlet set point 1 Condenser -- -- -- O --
17 ISP 2 C: Inlet set point 2 Condenser -- -- -- O --
18 SP1: Set point 1 thermostat -- -- O -- --
19 SP2: Set point 2 thermostat -- -- O -- --
ESIE05-07.book Page 58 Wednesday, October 11, 2006 10:42 AM
