ESIE05-07 The Functional Controller for DICN
Part 2 – Functional Description 2–79
3
2
4
5
1
P STEP 2: SELECT THE MASTER-SLAVE OPTION (ON THE MASTER AND SLAVES)
This screen allows you to modify the master-slave option
Line 4 ( DICN option) is not visible on ER units.
Service screen 1:
P Change the MS OPTION to Yes
P STEP 3: SELECT UNIT PRIORITY -STEPL PRIORITY (ON THE MASTER AND SLAVE)
Line 4 is only visible if MS option setting = Yes
Remark: Unity priority - stepL Priority
The first digit of the Master Slave Priority refers to the Unit priority. With this digit you can give
each unit a certain start up priority.
The second digit refers to the Step Length priority. This setting reacts only on load up steps
and avoids that one of the DICN units goes into freeze-up alarm because the common
leaving water is still to high.
Line n° Display Description Default Possible settings
1 SERVICE MENU Screen title
2 MIN. OUTL.
WATER
To select the mini-
mum outlet water
temperature
4°C From -10 till 8
3 FINETUNE(BMS) To select the com-
munication interval
30s From 0s till 60s
4 MS OPTION To select mas-
ter-slave option
yes or no
NY or N
Line n° Display Description Default Lower limit Upper limit
1 SERVICE MENU Screen title
2.1 C12%: Set the timer to run in
12% mode to start up
20s 20s 180s
2.2 START: Timer to set the compres-
sor to the first capacity
step for a certain time
before the first loadup is
allowed
180s 20s 360s
3.1 STOP: Timer to set to 12%
before stop.
8s 0s 99s
3.2 HP SETBACK: Function used to prevent
the unit from going into
high pressure safety
15.5bar
(R134a)
15.5 bar 17.0 bar
24.5bar
(R407C)
23.5 bar 26.0 bar
4.1 MS PR: Unit priority -stepL
Priority
0-2 0-0 3-4
4.2 AI3: Offset of analogue input 3 0°C -0.5°C +0.5°C
ESIE05-07.book Page 79 Wednesday, October 11, 2006 10:42 AM
