The Functional Controller for DICN ESIE05-07

2–78 Part 2 – Functional Description

Place of dipswitches on the User terminal:

Place of dipswitches on the EEV driver:

Settings on the

controller

DICN settings for the pCO2 controller

Remark: The remote start/stop, is the same as with individual units. In case of DICN, the remote

start/stop to be used, is the one from then master unit. In case of a disconnect unit, you must use the

remote start-stop of this unit.

P STEP 1: GO TO THE SERVICE MENU

You need the password to enter this menu. The unit leaves the factory with password fixed to "1914"

(to enter the user menu, use default password 1234).

Remark: When the unit is running it is not possible to enter the service menu.

Line n° Display Description

1 ENTER SERVICE Screen title

3 PASSWORD: 0000 Enter the correct password
