10-013816-01EN, Rev. 2, June 2020
Chapter 794
Magnetic field strength
of wheels
4.67×10
-9
milligauss (mG) at a distance of 2.1 m (7 ft)
away from the wheels. (This below the 5.25 milligauss
limit at which restriction would be imposed on air
shipment.)
Magnetic strength (one
raw magnet on a steel
plate)
78.9 lb (35.7 kg)
Minimum longitudinal
scanning pipe diameter
Outside scanning: 152 mm (6 in.) OD
Inside scanning: 1829 mm (72 in.) ID
Minimum
circumferential scanning
pipe diameter
Outside scanning:
4 probes: 254 mm (10 in.) OD
2 probes: 114.3 mm (4.4 in.) OD
Inside: 1219 mm (48 in.) ID
Table 15 Operating environment specifications
Parameter Value
Operating temperature ‒10 °C to 45 °C (14 °F to 113 °F)
Storage temperature ‒20 °C to 60 °C (‒4 °F to 140 °F)
Relative humidity (RH) Max. 85 % RH non-condensing
Wet location Yes
Altitude Up to 2000 m
Outdoor use Yes
Pollution degree 4
IP rating IP57
High temperature
operating
Standard MIL-STD 810H Method 501.7 Procedure
II, §4.5.3
Low temperature
operating
Standard MIL-STD 810H Method 502.7 Procedure
II, §4.5.3
High temperature
storage
Standard MIL-STD 810H Method 501.7 Procedure I,
§4.5.2
Low temperature storage Standard MIL-STD 810H Method 502.7 Procedure I,
§4.5.2
Table 14 General specifications (continued)
Parameter Value
