10-013816-01EN, Rev. 2, June 2020
Important Information — Please Read Before Use 9
The DANGER signal word indicates an imminently hazardous situation. It calls
attention to a procedure, practice, or the like that if not correctly performed or
adhered to will result in death or serious personal injury. Do not proceed beyond a
DANGER signal word until the indicated conditions are fully understood and met.
The WARNING signal word indicates a potentially hazardous situation. It calls
attention to a procedure, practice, or the like that if not correctly performed or
adhered to could result in death or serious personal injury. Do not proceed beyond a
WARNING signal word until the indicated conditions are fully understood and met.
The CAUTION signal word indicates a potentially hazardous situation. It calls
attention to a procedure, practice, or the like that if not correctly performed or
adhered to may result in minor or moderate personal injury, material damage,
particularly to the product, destruction of part or all of the product, or loss of data. Do
not proceed beyond a CAUTION signal word until the indicated conditions are fully
understood and met.
Note Signal Words
The following safety symbols could appear in the documentation of the scanner:
The IMPORTANT signal word calls attention to a note that provides information that
is important or essential to the completion of a task.
The NOTE signal word calls attention to an operating procedure, practice, or the like,
that requires special attention. A note also denotes related parenthetical information
that is useful, but not imperative.
DANGER
WARNING
CAUTION
IMPORTANT
NOTE
