10-013816-01EN, Rev. 2, June 2020
Scanner Assembly and Setup 33
2. Scanner Assembly and Setup
The AxSEAM scanner is designed so that part changes and adjustments can be easily
carried out.
2.1 Changing the Probe Holder Mounting Rail Angle for Longitudinal
Scanning
The probe holder mounting rails—and consequently, the probe orientation relative to
the surface being inspected—is changed by using the longitudinal scanning pivot
system. It is recommended to set the probe holder mounting rails as follows.
• Pipe diameters from 152.4 mm (6 in.) up to 406.4 mm (16 in.): set at the lowest
position.
• Pipe diameters from 406.4 mm (16 in.) and up: set at the upper position.
To change the probe holder mounting rail angle
1. Turn counterclockwise the knobs at the end of the two front probe holder
mounting rails and pull them. When they are loosened enough, the knobs pop out
of the threads, remaining attached to the scanner (Figure 2-1 on page 34).
