Olympus AxSEAM [32/116] Umbilical attachment

10-013816-01EN, Rev. 2, June 2020

Chapter 124

For the OmniScan MX flaw detector, an optional adaptor is required (P/N: U8780329).

For the TomoScan FOCUS LT acquisition instrument, an optional cable is required

(P/N: U8769010).

Figure 1-4 Encoder for measuring scanner position on the surface

1.2.7 Umbilical Attachment

The umbilical can quickly be attached or detached from the scanner using a thumb

screw located underneath the frame.

1.2.8 Quick-Reference Probe Holder Position Rulers

Rulers are provided on top of the scanner frame bar sections to help position the

probe holders at the same distance from the center of the scanner (Figure 1-5 on

page 25).

NOTE
