Olympus AxSEAM [61/116] Figure 2 25 water tubing assembly

10-013816-01EN, Rev. 2, June 2020

Scanner Assembly and Setup 53

Figure 2-25 Water tubing assembly

Use a hexagonal

key to unscrew.

UT probe

right side

UT probe

left side

PA probe

right side

PA probe

left side
