Figure 7-4 Length and width measurements for the short TOFD yoke

7.2 Connectors

The AxSEAM scanner includes the following cables:

• Scanner to OmniScan MX2 or OmniScan X3 instrument cable

• Encoder cable

The scanner to OmniScan cable signal correspondence, function, and pinout is shown

in Table 18 on page 98.

Table 17 Short yoke (TOFD)

Max (mm)

Min (mm)

(mm)

Button

diameter

(mm)

55 31.75 29.72 5

Table 18 Scanner to OmniScan cable connector pin numbers and functions

OmniScan pin

number

Function

Scanner pin

number

2+5V1

3 Digital input 1 9
