Olympus AxSEAM [70/116] Adjusting the probe separation distance
![Olympus AxSEAM [70/116] Adjusting the probe separation distance](/views2/1665793/page70/bg46.png)
10-013816-01EN, Rev. 2, June 2020
Chapter 362
3.4 Adjusting the Probe Separation Distance
Class 1 laser radiation. The laser of this product is a Class 1 laser under the IEC60825-1
(2014). Class 1 laser products are safe during use, including long-term direct
intrabeam viewing, even when exposure occurs while using optical viewing
instruments (eye loupe or binoculars).
To adjust the probe separation distance
1. Make sure that the magnetic ruler is on the pipe with its zero position aligned
with the center of the weld and positioned under the probes to be adjusted.
2. Align the scanner laser light with the zero on the ruler.
3. With the probes in contact with the ruler (probe holder latch released), turn the
probe holder positioning lever counterclockwise to unlock it.
4. Slide the probe holder left or right to set the correct probe offset.
5. Turn the probe holder positioning lever clockwise to lock it in place.
6. Repeat for the other probes.
7. Pull up on all probe holders so the probes are latched in their upper position.
8. Roll the scanner until the second pair of probes are over the ruler.
9. Release the probe holders so the wedge comes in contact with the ruler.
10. Remove the ruler from the part.
WARNING
