Olympus AxSEAM [9/116] Labels and symbols

10-013816-01EN, Rev. 2, June 2020

Labels and Symbols 1

Labels and Symbols

Marking locations of the scanner are shown in Figure i-1 on page 1. If any or all of the

labels or symbols are missing or illegible, please contact Olympus. The descriptions of

the symbols are provided in Table 1 on page 2.

Figure i-1 Rating label location on scanner

Scanner regulatory and

serial number labels

Class 1 laser
