Olympus AxSEAM [105/116] Figure 7 3 length and width measurements for the long pa yoke

10-013816-01EN, Rev. 2, June 2020

Specifications 97

Figure 7-3 Length and width measurements for the long PA yoke

Table 16 Long yoke (PA)

Max (mm)

Min (mm)

far position

(mm)

close position

(mm)

Button

diameter

(mm)

55 31.75 54.86 37.85 8
