Olympus AxSEAM [95/116] Spare parts 87
![Olympus AxSEAM [95/116] Spare parts 87](/views2/1665793/page95/bg5f.png)
10-013816-01EN, Rev. 2, June 2020
Spare Parts 87
Table 9 Cable management spare parts
Drawing
number
Quantity
a
a. This number represents the typical quantity initially included with your scan-
ner package.
Part number Description
1 1 Q8301783 Clamp cable sleeve
2 1 Q8301784 Holder sleeve frame
3 1 Q8301785
Q8301786
Cable management sleeve 5 m
Cable management sleeve 10 m
4 1 Q8301762 Screw thumb circumferential pivot
5 1 Q8301763 Spring comp. OD 0.25 lenght 0.47
6 1 Q8301764 Ring retaining ext low clearance 4 mm
7 1 Q8301787 Screw M4 × 10 mm hex head stain
8 1 U8908516 Washer flat M4 stain
9 20 U8902320 Tubing ID-4 mm OD-6 mm blue-trans
10 1 U8902319 QS-8-6 push-in reducing
11 0.5 U8902318 Tubing id-5 mm od-8 mm blue
12 1 Q8301788
Q8301789
Cable LEMO M-M 1K.316 to 1T.310
5m
Cable LEMO M-M 1K.316 to 1T.310
10 m
13 1 Q8301790 Tubing kit
14 7 U8902321 Y adaptor for irrigation tubing
17 5 U8900341 Tubing ID-1/8 OD-1/4
21 1 U8908626 QH-QS-6 valve
22 1 U8902320 Tubing ID-4 mm OD-6 mm blue-trans
