1.2.3 Circumferential Inspection Scanning Pivot System
This system is used to adapt to different pipe diameters when scanning in the
circumferential direction. For the pipe diameters of 406.4 mm (16 in.) and smaller, put
the system in its pivoted position. For the pipe diameters greater than 406.4 mm
(16 in.), put the system in its straight position.
1.2.4 Wheels
The shape of the wheels allows them to work on the entire diameter range without
requiring any adjustments. The wheels are magnetized with polyurethane rolling
surface to allow a smooth and steady movement over rough surfaces (Figure 1-3 on
page 23).
Before handling the scanner, observe the following general safety precautions related
to its magnetic wheels (see “Replacing Wheels” on page 70 for complete details on
wheel safety):
• The magnetic fields around the wheels may affect pacemakers, watches, and
other sensitive electronic devices, and anyone relying on such devices must keep
a safe distance away from the wheels to avoid the risk of serious injury or death.
• Magnetic wheels present a risk of finger crushing if fingers are placed between
the wheels and a ferromagnetic surface.
• The magnets are strong and will be attracted to any ferromagnetic surface
WITHOUT warning, which can cause injury, equipment damage, or malfunction.
Ensure that your feet have a solid grip on the floor. Use a rubber carpet when the
floor is wet and slippery.
WARNING
