10-013816-01EN, Rev. 2, June 2020
Introduction 17
Introduction
This manual provides instructions for assembling, installing, and operating the
AxSEAM scanner. The AxSEAM scanner is a versatile pipe and tube semi-automatic
scanner that can be used to inspect longitudinal welds on pipes of 152.4 mm (6 in.)
outside diameter (OD) and greater as well as circumferential welds on pipes of
254 mm (10 in.) OD and greater.
The AxSEAM was designed to be easy to set up. Only a few operations are required to
adapt to a new diameter or configuration. No tools is necessary to operate the
AxSEAM.
This manual is organized to allow a progressive understanding of the scanner’s
different functions. Each section, however, is complete in itself. This manual is
therefore a useful reference.
The AxSEAM scanner is designed to be used with an OmniScan series instrument. For
details on instrument and software operation, refer to the OmniScan MX, MX2, and X3
User’s Manual or OmniScan SX User’s Manual, as well as the OmniScan MXU Software
User’s Manual.
