10-013816-01EN, Rev. 2, June 2020
Important Information — Please Read Before Use14
manual, might cause harmful interference to radio communications. Operation of this
product in a residential area is likely to cause harmful interference, in which case you
will be required to correct the interference at your own expense.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the product.
FCC Supplier’s Declaration of Conformity
The supplier hereby declares that the product,
Product name: AxSEAM
Model: AxSEAM-X-XXX, AxSEAM-XXX, AxSEAM-XX-XXXXX
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107 and Section 15.109.
Supplementary information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Responsible party name:
Olympus Scientific Solutions Americas Corp.
Address:
48 Woerd Avenue, Waltham, MA 02453, USA
Phone number:
+1 781-419-3900
ICES-001 (Canada) Compliance
This Class A digital apparatus complies with Canadian ICES-001.
WARNING
