10-013816-01EN, Rev. 2, June 2020

Labels and Symbols2

Table 1 Content of the rating label

Class 1 Laser

Product label

Scanner

regulatory label

Scanner serial

number label

Content

The CE marking is a declaration that this product conforms to

all the applicable directives of the European Community. See

the Declaration of Conformity for details. Contact your Olympus

representative for more information.

The regulatory compliance mark (RCM) label indicates that

the product complies with all applicable standards, and has

been registered with the Australian Communications and

Media Authority (ACMA) for placement on the Australian

market.

The WEEE symbol indicates that the product must not be

disposed of as unsorted municipal waste, but should be

collected separately.
