10-013816-01EN, Rev. 2, June 2020
Labels and Symbols 3
The direct current symbol.
S/N The serial number is in the following format: QC-XXXXXX
where: QC represents where the unit was manufactured
(Quebec City) and XXXXXX represents a six-digit number.
Seller and user shall be noticed that this equipment is suitable
for electromagnetic equipment for office work (class A) and it
can be used outside home.
The MSIP code for the AxSEAM is the following: R-R-OYN-
AXSEAM.
The warning symbol indicates that the user must read the
user’s manual in order to find out the nature of the potential
hazards and any actions to avoid them.
The China RoHS mark indicates the product’s Environment-
Friendly Use Period (EFUP). The EFUP is defined as the
number of years for which listed controlled substances will not
leak or chemically deteriorate while in the product. The EFUP
for the AxSEAM has been determined to be 15 years. Note:
The Environment-Friendly Use Period (EFUP) is not meant to
be interpreted as the period assuring functionality and
product performance.
Table 1 Content of the rating label (continued)
