10-013816-01EN, Rev. 2, June 2020

Chapter 234

Figure 2-1 Probe holder mounting rail in upward position

2. Pivot the two probe holder mounting rails until they reach their travel limits

(Figure 2-2 on page 34).

Figure 2-2 Probe holder mounting rails in downward position

Probe holder mounting rail pivoting system knobs
