BASIC OPERATION
■ Optional voice scrambler operation
DD
Activating the scrambler
The optional voice scrambler provides private communica-
tions. In order to receive or send scrambled transmissions
you must first activate the scrambler function. To activate the
function, an optional UT-112 is necessary. See p. 47 for set-
ting the scrambler unit. Ask your dealer for details.
The scrambler function automatically turns OFF when
Channel 16 or 70 is selected.
q
Select an operating channel other than Channel 16 and 70.
w Push [F], then push [0 SCRM] to turn the optional scram-
bler function ON.
• “SCRAM” appears.
e To turn the scrambler function OFF, repeat step w.
• “SCRAM” disappears.
DD
Programming scrambler codes
There are 32 codes (1 to 32) available for programming when
the optional UT-112 is installed. In order to understand one
another, all transceivers in your group must have the same
scramble code. This function may not be available depend-
ing on dealer setting.
q Turn power OFF.
w While pushing [16•9], turn power ON to enter set mode.
e After the display appears, release [16•9].
r Rotate [CHANNEL] to select the “Scrambler Code,”
push [ENT].
t Rotate [CHANNEL] to select the desired scrambler code.
y Push [ENT] to set and exit the scrambler code item.
u Rotate [CHANNEL] to select “Exit,” then push [ENT] to
exit set mode.
Enter set mode
POWER
+
9
16
ENT ENT
Select item
then push
Select code
then push
Scrambler Code
˘9
˘7
--Set Mode--
˘5
˘6
˘8
˘<ENT˘OK>
˘Scan Type
˘Scan Timer
--Set Mode--
˘Internal Speaker
˘Contrast
˘Beep
˘Dual/Tri COMMANDMIC
˘WX Alert
˘Internal Speaker
˘Contrast
--Set Mode--
˘Scrambler Code
˘Exit
˘Scrambler Type
˘Foghorn Frequency
˘RF Attenuator
[Example]: Programming scrambler code 8.
